OUR SPACE PORTFOLIO

A vertical line of black text and dots on a white background, arranged with increasing frequency toward the bottom of the image.

OUR SPACE PORTFOLIO

A vertical line of black text and dots on a white background, arranged with increasing frequency toward the bottom of the image.

space heritage

Space heritage can be used as an asset that reduces qualification efforts for processes and components that have successfully been in space before and are built under the same conditions for new missions.
This allows components that have already been tested and qualified for previous space missions to be reused without having to go through the entire Technology Readiness Level (TRL) verification again and thus saves significant time and money. EAGLEYARD supports such approach to save its customers budgets based on our comprehensive space program experience, knowledge and heritage.

space qualified

Typically, the result of a customized project with mission-specific requirements driven by the customer, including EAGLEYARD transparency provision of its own space heritage of materials and processes followed by LOT Acceptance Test campaigns and dedicated qualification tests conducted by our Quality Management. It is usually completed with the delivery of the required Flight Models or experimental Flight Models and execution of all related mandatory inspection points and milestones as well as the requested documentary.

space qualifiable

At this level EAGLEYARD guarantees manufacturing and testing of the laser diodes in accordance with its own experience of space related requirements. It includes a specialized bill of materials, customized processes, documentation and additional quality gates. The responsibility of the successful mission suitability of the products itself remains with the customer, because all the corresponding space verification and qualification activities stay with the customer. EAGLEYARD only guarantees the proper design and workmanship compliant with the referenced standards or procedures.

industry level

Laser diodes built on extensive experience in high-reliability industrial applications accompanied by necessary quality assurance procedures.

space Projects

LISA (ESA/
NASA)

RWL 808 nm as pump
laser for µNPRO

2037

The image is completely blank with a plain white background and no visible objects or text.
Blank white background with no visible objects or text.

DRAGONFLY
(Nasa)

DFB 1064 nm

2028

MERLIN
(DLR/CNES)

DFB 1064 nm & DFB 1645 nm

2028

Blank white background with no visible objects or features.
The image is blank with a white background and no visible objects, text, or features.

FORUM (ESA)

DFB 1064 nm

2027

GALILEO G2
(HE-ESA)

DFB 780 nm

2026

The image is blank with a plain white background and no visible objects or text.
The image is completely blank with a white background and contains no visible objects or text.

Cold Atom Lab ISS
(NASA/JPL)

RWE 790 nm, TPA 780 nm

2018

EXO Mars (ESA)

DFB 760 nm

2016

Blank white background with no visible objects or text.
Blank white background with no visible objects or features.

CATS (Nasa)

DFB 1064 nm

2015

GAIA (ESA)

DFB 852 nm operated 11
years successfully in space

2013

Image is completely blank with a white background and no visible objects or text.

OUR SPACE PORTFOLIO

INTERFEROMETRY & LIDAR

  • DFB laser diodes @ 1064 nm with output powers from 25 mW – 40 mW cw mode and 600 mW pulsed mode
  • all in hermetically sealed butterfly packages with fiber or free beam
  • µMOPA @ 1064 nm with output power of 2 W cw or > 6 W pulsed mode in hermetically sealed butterfly package

OPTICAL CLOCKS

  • DFB laser diodes @ 780 nm with output powers
 from 20 – 80 mW
  • DFB laser diodes @ 795 nm with output powers
 from 40 mW – 80 mW
  • DFB laser diodes @ 852 nm with output powers
 from 15 mW – 100 mW
  • all in hermetically sealed butterfly packages with fiber
or free beam
  • DFB laser diode @ 895 nm with output power
of 50 mW in TO-package

OXYGEN & METHANE GAS DETECTION

  • DFB laser diodes @ 760 nm with output powers from
15 mW – 40 mW in hermetically sealed butterfly or TO-packages
  • DFB laser diodes @ 1645 nm with 100 mW output power hermetically sealed butterfly package

INTER- & INTRA-SATELLITE
COMMUNICATION

  • Fabry Perot laser diode @ 808 nm with 400 mW – 800 mW
  • in hermetically sealed butterfly packages with fiber or free beam

OUR SPACE PORTFOLIO

OXYGEN & METHANE GAS DETECTION
  • DFB laser diodes @ 1064 nm with output powers SPACE HERITAGE from 25 mW – 40 mW cw mode and 600 mW pulsed mode
  • all in hermetically sealed butterfly packages with fiber or free beam
  • µMOPA @ 1064 nm with output power of 2 W cw or > 6 W pulsed mode in hermetically sealed butterfly package

OPTICAL CLOCKS
  • DFB laser diodes @ 780 nm with output powers
 from 20 – 80 mW
  • DFB laser diodes @ 795 nm with output powers
 from 40 mW – 80 mW
  • DFB laser diodes @ 852 nm with output powers
 from 15 mW – 100 mW
  • all in hermetically sealed butterfly packages with fiber
or free beam
  • DFB laser diode @ 895 nm with output power
of 50 mW in TO-package

OXYGEN & METHANE GAS DETECTION
  • DFB laser diodes @ 760 nm with output powers from
15 mW – 40 mW in hermetically sealed butterfly or TO-packages
  • DFB laser diodes @ 1645 nm with 100 mW output power hermetically sealed butterfly package

INTER- & INTRA-SATELLITE COMMUNICATION
  • Fabry Perot laser diode @ 808 nm with 400 mW – 800 mW
  • in hermetically sealed butterfly packages with fiber or free beam
